7
Revised 4-21-10
Part # MJ-OUT StudioHub+ MatchJack Preamp, Output
(856) 467-8000
•
Fax (856) 467-3044
•
www.studiohub.com
JU1
Install to connect
shield ground to
power ground
Left level adjust
Right level adjust
Direct power input
+/- 15 volts DC
Right input RCALeft input RCA
Audio and power input
provided on RJ-45
Power
LED
