Revised 4-21-10
Part # MJ-IN StudioHub+ MatchJack Preamp, Input
(856) 467-8000
•
Fax (856) 467-3044
•
www.studiohub.com
JU1
Install to connect shield ground
to power ground
Left level adjust
Right level adjust
Audio and power input
provided on RJ-45
Direct power input
+/- 15 volts DC
Right output RCA
Power
LED
