Radstone PowerPact - Bit

PowerPact6 Processors Family Product Manual
System Set-up
1
st
Edition 4-6
BIT
Radstone’s Built In Test (BIT) software comprises a suite of self-test programs designed to run on the
full range of boards and systems manufactured by Radstone Technology.
On power up or hard reset, BIT displays a start banner detailing the BIT version, PowerPact6 type
(CP1A in the example below), available memory etc. This is followed by the first tests - BIT checksum
and MPE (Minimum Processing Environment) tests. A typical full BIT start sequence is shown below:
Radstone Technology Plc PPCBIT V3.0.0.0 ALPHA
=======================================
Board Type : CP1A Mem Bus Speed 133Mhz ; MPC7447A 1133MHz Revision : 1A
Memory : 512 Mb DRAM, ECC Disabled
Cache : 1024 Kb L2,
Flash : 8 Mb System FLASH : 248 Mb User FLASH
CPCI : System Board Slot ID = 5,
PCI : PMC2 IO = 3.3V ; PMC1 IO = 3.3V
Ports : COM 3-6
Ethernet : Ch1 Gigabit Ethernet ; Ch2 Gigabit Ethernet
Modules :PMC1 : OUT PMC2 : OUT AFIX : OUT
BIT : Master
Boot Mode : MAIN
PPCBIT Details
==============
Version No: V3.0.0.0 ALPHA
Part No. : TB0712-001
Built : Aug 18 2005 15:40:55
.....
BIT Checksum = d98ca94e
MPE tests successful
Restored System Description...
Copy of System Description Table at ffa82200
============================================
SDE CIIN ROUTINE ADDRESS BUS AM METHOD LENGTH GRAN SKP TESTMASK
--- ---- ------- ------- --- -- ------ ------ ---- --- --------
000 CP1A 0006339c 00000000 LOCAL SELF_TEST 0100 NO 00000000
CP1A (00000000 LOCAL SELF_TEST )
Passed TM 00000001 [Timebase & Decrementer Test]
Passed TM 00000002 [ISA Bridge Test ]
Passed TM 00000004 [Hardware Register Test ]
Passed TM 00000008 [Main DRAM Test ]
Passed TM 00000010 [PowerPC Cache Test ] L1 Only
Passed TM 00000020 [PowerPC MMU Test ]
Passed TM 00000040 [PowerPC FPU Test ]
Passed TM 00000080 [PCI Bus Test ]
Passed TM 00000100 [Discovery Timer Test ]
Passed TM 00000200 [Discovery COM 3/4 Test ]
Passed TM 00000400 [Discovery Ethernet 1 Test ]
Passed TM 00000800 [Discovery Ethernet 2 Test ]
Passed TM 00001000 [Discovery I2C TEMP Test ]Temperature 29.18C
Passed TM 00002000 [Discovery I2C RTC Test ]
Passed TM 00004000 [HB6 Bridge 1 Test ]
