PowerPact6 Processors Family Product Manual
System Set-up
1
st
Edition 4-7
Passed TM 00008000 [HB6 Bridge 2 Test ]
Passed TM 00010000 [HB6 Bridge 3 Test ]
Passed TM 00020000 [PCI USB2 Test ]
Passed TM 00040000 [GPIO/Floppy/LPT Test ] GPIO
Passed TM 00080000 [PS2 Keyboard + Mouse Test ]
Passed TM 00100000 [Serial Port COM1 Test ]
Passed TM 00200000 [Serial Port COM2 Test ]
Passed TM 00400000 [Serial Port COM5 Test ]
Passed TM 00800000 [Serial Port COM6 Test ]
Passed TM 01000000 [System Flash (Main) Test ] Checksum Only
Passed TM 02000000 [System Flash (Ext) Test ] Checksum Only
Passed TM 04000000 [System Flash (Alt) Test ] Checksum Only
Passed TM 08000000 [System Flash (Bank) Test ] Checksum Only
Ignored TM 10000000 [User Flash Test ] Ignored on power up
Passed TM 20000000 [NVRAM Test ] PPCBOOT No Test
Passed TM 40000000 [Dummy Test ]
Passed TM 80000000 [Beep Test ]
CP1A (00000000 LOCAL SELF_TEST ) passed
Default action is Options Menu
Press any key to abort default action...
Options Menu
============
1. System Description.
2. Special Functions
3. Comprehensive BIT.
4. Default BIT, Application.
5. Execute Application.
6. Interactive BIT.
7. Edit Configuration.
8. Debug.
Select option >
PPCBoot
PowerPact6 processors do not support SCSI disks, so PPCBoot’s primary role here is to boot cross-
development operating systems (such as LynxOS) across a network. Consult the documentation supplied
with the software (e.g. LynxOS) for more details. An example of booting LynxOS across a network is
given below.
On startup, PPCBoot displays a start banner that identifies the PowerPact6 system configuration - see
below.
PPCBoot 2.0.0 (Aug 24 2005 - 11:15:13), Build: 31590 Radstone Version 1.1b booted
from Alt boot area
CPU: MPC7447A v1.1 @ 1133.333 MHz
Board: CP1A Rev 1A #12345678 Slot ID: 0x01
I2C: ready
Temp: board: 31 C, 37 C cpu: 56 C
DRAM: 512 MB
FLASH: 256 MB
In: serial
Out: serial
Err: serial
AFIX: not fitted
CPCI: System Controller
SCSI: disabled
Net: mv_enet0 [PRIME], mv_enet1
=>
