Radstone PowerPact - Geographical Address Pin Assignments

PowerPact6 Processors Family Product Manual
Standard Interfaces
1
st
Edition 5-7
Geographical Address Pin Assignments
SLOT
GA4
PIN J2-A22
GA3
PIN J2-B22
GA2
PIN J2-C22
GA1
PIN J2-D22
GA0
PIN J2-E22
1 GND GND GND GND Open
2 GND GND GND Open GND
3 GND GND GND Open Open
4 GND GND Open GND GND
5 GND GND Open GND Open
6 GND GND Open Open GND
7 GND GND Open Open Open
8 GND Open GND GND GND
9 GND Open GND GND Open
10 GND Open GND Open GND
11 GND Open GND Open Open
12 GND Open Open GND GND
13 GND Open Open GND Open
14 GND Open Open Open GND
15 GND Open Open Open Open
16 Open GND GND GND GND
17 Open GND GND GND Open
18 Open GND GND Open GND
19 Open GND GND Open Open
20 Open GND Open GND GND
21 Open GND Open GND Open
22 Open GND Open Open GND
23 Open GND Open Open Open
24 Open Open GND GND GND
25 Open Open GND GND Open
26 Open Open GND Open GND
27 Open Open GND Open Open
28 Open Open Open GND GND
29 Open Open Open GND Open
30 Open Open Open Open GND
31 Open Open Open Open Open
$
Note: Geographical addressing is accessed and controlled via software (BSP), the function of which
requires configuration before it may be used – see the appropriate BSP documentation.
