Radstone PowerPact - Jx3 (64-Bit PCI) Connector Pinout

PowerPact6 Processors Family Product Manual
Standard Interfaces
1
st
Edition 5-10
Jx3 (64-bit PCI) Connector Pinout
PIN SIGNAL PIN SIGNAL
1 Reserved (PCI) 2 GND
3 GND 4 CBE(7)~
5 CBE(6)~ 6 CBE(5)~
7 CBE(4)~ 8 GND
9 VIO 10 PAR64
11 AD(63) 12 AD(62)
13 AD(61) 14 GND
15 GND 16 AD(60)
17 AD(59) 18 AD(58)
19 AD(57) 20 GND
21 VIO 22 AD(56)
23 AD(55) 24 AD(54)
25 AD(53) 26 GND
27 GND 28 AD(52)
29 AD(51) 30 AD(50)
31 AD(49) 32 GND
33 GND 34 AD(48)
35 AD(47) 36 AD(46)
37 AD(45) 38 GND
39 VIO 40 AD(44)
41 AD(43) 42 AD(42)
43 AD(41) 44 GND
45 GND 46 AD(40)
47 AD(39) 48 AD(38)
49 AD(37) 50 GND
51 GND 52 AD(36)
53 AD(35) 54 AD(34)
55 AD(33) 56 GND
57 VIO 58 AD(32)
59 Reserved (PCI) 60 Reserved (PCI)
61 Reserved (PCI) 62 GND
63 GND 64 Reserved (PCI)
