PowerPact6 Processors Family Product Manual

Standard Interfaces

Edition 5-13

AFIX Interface

For enhanced I/O flexibility, the PowerPact6 processors offer a ‘plug-on’ module interface that adds rear

I/O functionality via J4 and J5. The Additional Flexible Interface Xtension (AFIX) card is a factory fitted

option and is fully rugged.

Figure 5-3. AFIX Connector Position and Numbering
