Rain Bird ESP-Me User Manual

Installation
ENG
ESP-Me Controller
11
Connect Power

WARNING: DO NOT plug in the transformer or
connect external power until you have com-
pleted and checked all wiring connections.

WARNING: Electric shock can cause severe injury
or death. Make sure power supply is turned OFF
before connecting power wires.
Electrical Specications
Input 230VAC, 0.2AMP, 50/60Hz
Output 25.5VAC, 1.0AMP, 50/60Hz
Power Wiring Connections
230 VAC (International)
Brown supply wire (hot) to the brown transformer wire
labeled with “L”
Blue supply wire (neutral) to the blue transformer wire
labeled with “N”
Green-with-yellow-stripe supply wire (ground) to the
green-with-yellow-stripe transformer wire

Rain Bird ESP-Me Specifications

General

Type	Modular
Start Times per Program	4
Master Valve/Pump Start	Yes
Watering Start Times	4 per program
Cycle and Soak	Yes
Rain Delay	Yes
Power Source	24V AC
Voltage	24V AC
Station Run Times	1 minute to 4 hours
Backup Battery	No
