Rain Bird ESP-Me User Manual

Program START Station Scheduled Start Actual Start Run Times
A 1
st
1
8:00 AM
8:00 AM 30 MIN
2 8:30 AM 30 MIN
3 9:00 AM 30 MIN
4 9:30 AM 30 MIN
B 1
st
5
8:00 AM
10:00 AM 30 MIN
6 10:30 AM 30 MIN
7 11:00 AM 30 MIN
8 11:30 AM 30 MIN
Normal Operation
ENG
ESP-Me Controller
18
Program-Based Scheduling
The ESP-Me uses a programmed-based scheduling
method to create irrigation schedules.
For each Program (A, B, C and D):
A
Select Watering Days (Custom, Odd/Even, Cyclic)
and Start Times that apply globally to the entire
program.
B
Assign a Run Time to each available station
number to run during the selected program.
Program Stacking
If any programs have Start Times that overlap, the ESP-
Me will “stack” the Start Times. When all Stations have
run in Program A, then Program B will start watering.
Individual stations will water in sequential order.
As an example: Program A and B are both set to start
at 8:00 AM. But Program B will not run until Program A
is nished.
With Program Stacking,
Program B only starts
when Program A is
nished

Rain Bird ESP-Me Specifications

General

Type	Modular
Start Times per Program	4
Master Valve/Pump Start	Yes
Watering Start Times	4 per program
Cycle and Soak	Yes
Rain Delay	Yes
Power Source	24V AC
Voltage	24V AC
Station Run Times	1 minute to 4 hours
Backup Battery	No
