Receiver:
• Frequency: 100 kHz to 1.0 GHz
• Step size: 10 Hz
• Sensitivity: Less than 2 uV, 1 MHz to 512 MHz; less than 3 uV, 512 MHz to 1 GHz; un-
specified, 100 kHz to 1 MHz
• FM Demod: 0 to 7 kHz, 0 to 4 kHz
• AM Demod: 0 to100%
• CTS Decode: In AF frequency count
• Frequency error: 0 to1 MHz, two methods of bargraph and count
• AF Demod output: 1 Vp-p for 7 kHz deviation
• Gates: 0.1 Sec, 1 Sec
Audio counter:
• Frequency Range: 60 Hz to 3000 Hz
• Gates: 10 Sec variable gate for 1 Sec quick updates
• Sensitivity: 35 mV at demod audio, 750 Hz deviation
Frequency counter:
• Frequency Range: 100 kHz to 1.0 GHz
• Low Band Sensitivity: Less than 10 mV under 70 MHz, 1 Hz and 10 Hz resolutions
• High Band Sensitivity: Less than 10 mV, 70 MHz to 1.0 GHz, 10 Hz and 100 Hz
resolutions with divide by ten pre-scaler
• IF Frequency: Receiver sensitivity. Frequency range limited to bandwidth of current
set receive frequency, 10 kHz. 1 Hz and 10 Hz resolutions
General:
• Receiver input has diode protection and fused parts
• Battery life: 1 hour per battery pack, 3 battery packs maximum
• Controls: Elastomeric
• RS232 Control: Serial interface provides external function control and automated cali-
bration
• Dummy Load: 100W 30 dB attenuator included, 25% duty cycle for rated power,
30dB sample port on rear panel
• Primary Power: 100-240 VAC, .6A, 50/60 Hz. Built-in 1 hour battery pack (holds 2
additional battery packs for 3 hour battery life
• Stand: Bottom mounted tilt bail stand included
• Supplied Accessories: 110 VAC EIA power cord, BNC-BNC test cable, whip antenna,
one BP3010 Li-Ion battery
• Case color: Mist gray epoxy powder coat
• Dimensions: 6” H x 11.9375” W x 14.75” D (152.4 mm H x 303.21 mm W x 374.65
mm D)
• Weight: 14 lbs (6.5kg)
COM3010 SPECIFICATIONS
Property of Ramsey Electronics, Inc.
