93
DETAILED INFORMATION
6.50.06 Various Meter Mode Options
Lower Meter
Mode Table
Mode # Mode Name Valid in AM Valid in FM
1 Frequency Error Graphic Yes Yes
2 Frequency Error Text Yes Yes
3 FM Modulation Graphic +/-7kHz No Yes
4 FM Modulation Graphic +/-4kHz No Yes
5 FM Modulation Text No Yes
6 AM Percent Graphic Yes No
7 AM Percent Text Yes No
8 Audio Frequency Counter Yes Yes
9 Sinad Meter Yes Yes
Upper Meter
Mode Table
1 RSSI Bargraph
2 RSSI Text
3 RF Power
4 Power Supply State/Voltage
Counter Mode
Table
Mode # Mode Name
1 Direct RF counter, 0-100MHz, 0.1S
gate
2 Direct RF counter, 0-100MHz, 1S
gate
3 Direct RF counter, 50-1200MHz,
0.1S gate
4 Direct RF counter, 50-1200MHz, 1S
gate
5 IF Frequency Counter (based on
receiver frequency), 0.1S gate
6 IF Frequency Counter (based on
receiver frequency), 1S gate
