21
BASIC OPERATION
2.06.04 Generating DCS
To activate DCS, press
The LED will light indicating it is on. The DCS code field is now active as indicated by the
blinking icon.
You must enter the DCS code with the UP / DOWN keys. You will be selecting from an
internal list stored in the COM3010. To select a code of 53, use the
keys to select the code.
For inverted digital code, press SHIFT, DCS; press them again to return to normal. Note the
“N” or “I” on the end of the code. To invert or de-invert the DCS code, press SHIFT, DCS to
toggle the code.
For example: If you had 53N selected for a code, pressing
will select 53I.
To enter a new deviation value for DCS code generation, press FM followed by the deviation
level desired, followed by Hz/uV.
Example: (For 500Hz deviation)
To turn off DCS, press
GENERATE TX Level
Modulation Seq/Reg
Your Notes:
