ADVANCED FEATURES
General Options (Continued)
On the RECEIVE screen:
The Dim function allows the user to use the UP/DOWN arrows to select the display intensity.
Access this option using the button.
[Exit&Save] exits this menu and saves all option settings using the key.
Splash allows disabling of the start up splash screen and is toggled using the key.
T
he Flt Cnt (Counter Filter) function allows disabling of the frequency counter filter. Press the
key to toggle this function.
Serial Port Options
will activate the Serial Port Menu and give you the following choices:
Serial
Port
Name:
Choices Default Description
Baud 300, 600, 1200,
2400,4800,
9600, 14400,
9200,28800,
57600, 115200
57600 Sets the Baud Rate of the COM3010 Serial Port,
always defaults in 8,n,1 communications.
Address 000 to 999 555 Allows user to view or change the Serial Port Ad-
dress
Reset
Pwd
YES / NO No If set to ‘YES’ upon exiting menu it will reset the
Serial Password to 1234.
Exit &
Save
Saves settings
GENERATE TX Level
Modulation Seq/Reg
RECEIVE Level Meters
Counter Freq Meters
