42
b
b
a
a
c
c
D
D
gas blenDer
ADD hE UP To: 135.0 BAR
ADD 02 UP To: 151.4 BAR
ToP UP WITh AIR
gas blenDer
AT 25°C ToTAL ADDED
02: 510L 246L
hE: 1650L 1275L
After pressing EVALUATE if the mix is possible with the inserted settings, the iX3M 2
will show the procedure to follow to obtain the desired mix.
In the example shown in the picture:
ADD HE UP TO: Add Helium in the tank until you reach 135 Bar of pressure
inside the tank.
ADD 02 UP TO: Add Oxygen in the tank until you reach151.4 Bar of pressure
inside the tank.
TOP UP WITH AIR: Add Air (21/00) inside the tank until you reach
the nal desired pressure (200 bar as in the example).
Do you know what?: In case the desired mix is not possible by using the inserted data, the iX3M 2 indicates
the reason.
Pressing the
D button the iX3M 2 visualizes more information on the Helium and
Oxygen volumes used (considering a temperature of 25°C)
TOTAL: The total quantity of gas (Oxygen or Helium) inside the tank.
ADDED: The gas quantity (Oxygen or Helium) added inside the tank to obtain
the desired blending.
At any time, press the
A button to exit.
