220 E-Series Networked Display Reference Manual
14.8Simulator
We recommend that you use the simulator to familiarize yourself with the AIS function.
When the system simulator is switched on (see
page 228
), it displays 20 AIS targets
within a 25nm range. These targets are displayed using the appropriate AIS targets
status symbol (see
page 214
) and move around the screen as if they were real targets.
Important: Incoming safety messages cannot be displayed while the simulator is
switched on.
14.9AIS Layer Setup Menu
The AIS Layer Setup Menu allows you to:
• Select the target types displayed (ALL or DANGEROUS).
• Switch the display of AIS safety messages ON/OFF.
• View the list of active AIS unit alarms.
To display the AIS Layer Setup Menu:
1. Set the AIS LAYER status to ON ((see
page 213
).
2. Select the AIS Layer Setup:
D8969_1
AIS Layer Setup
AIS Alarms List...
