2.1Productdocumentation
Thefollowingdocumentationisapplicabletoyour
product:
DescriptionPartnumber
Installationand
operationinstructions
81377
Ray90/Ray91mounting
template
87329
Alldocumentsareavailabletodownload
inpdfformatfromtheRaymarine®website:
www.raymarine.com/manuals.
UsermanualsPrintShop
RaymarineprovidesaPrintShopservice,enablingyou
topurchaseahigh-quality,professionally-printedmanual
foryourRaymarineproduct.
Printedmanualsareidealforkeepingonboardyour
vessel,asausefulsourceofreferencewheneveryou
needassistancewithyourRaymarineproduct.
Visithttp://www.raymarine.co.uk/view/?id=5175toorder
aprintedmanual,delivereddirectlytoyourdoor.
ForfurtherinformationaboutthePrintShop,
pleasevisitthePrintShopFAQpages:
http://www.raymarine.co.uk/view/?id=5751.
Note:
•Acceptedmethodsofpaymentforprintedmanuals
arecreditcardsandPayPal.
•Printedmanualscanbeshippedworldwide.
•FurthermanualswillbeaddedtothePrintShop
overthecomingmonthsforbothnewandlegacy
products.
•Raymarineusermanualsarealsoavailableto
downloadfree-of-chargefromtheRaymarine
website,inthepopularPDFformat.ThesePDF
filescanbeviewedonaPC/laptop,tablet,
smartphone,oronthelatestgenerationof
Raymarinemultifunctiondisplays.
Documentillustrations
Y ourproductandifapplicable,itsuserinterfacemay
differslightlyfromthatshownintheillustrationsinthis
document,dependingonproductvariantanddateof
manufacture.
Allimagesareprovidedforillustrationpurposesonly.
2.2Applicableproducts
Thisdocumentisapplicabletothefollowingproducts:
NamePartnumberFeatures
Ray90E70492•Built-inGNSS
(GPSand
GLONASS)
receiver
•Upto2wired
handsetstations
•Loudhailer
connection
•SeaTalkng®/
NMEA2000
connection
•NMEA0183
connection
Ray91E70493SameasRay90
above,with
additional:
•Built-inAIS
receiver
Requiredadditionalcomponents
Y ourproductrequiresaVHFandGNSS(GPS)antenna
tobeconnected.
PartnumberDescription
A80288
PassiveGNSS(GPS)antenna
N/A
3
rd
PartyVHFantenna
14
