Raymarine RAY91 Installation & Operation Instructions

2.5ObtainMMSI(Maritime
MobileServiceIdentity)number
Beforecommencinginstallationensureyouhave
obtainedaMMSInumberforyourvessel.
AMMSIisa9digitnumberwhichissentoveraradio
frequencychannelinordertoidentifytheoriginating
vessel/station.IfyourvesselalreadyhasaMMSInumber
(usedforaVHFDSCradio)thenthesameMMSInumber
mustbeusedtoprogramyourproduct.
Note:
IfaMMSInumberisnotentered,theDSCfunctionality
ofyourradiowillbedisabled.
IntheUnitedStatesofAmerica,theMMSIandStatic
DatamustbeenteredonlybyaRaymarine®dealer
orotherappropriatelyqualifiedinstallerofmarine
communicationsequipmentonboardvessels.
TheuserisNOTauthorizedtodothis.
Insomeareas,aradiooperatorlicenceisrequired
beforeaMMSInumberwillbeissued.Y oucanrequest
aMMSInumberfromsameagencythatissuesradioor
ShipRadiolicencesinyourarea.
InEuropeandotherpartsoftheworldoutsideofthe
UnitedStatesofAmerica,theMMSIandStaticdatacan
besetupbytheuser.
Forfurtherdetails,refertotherelevant
TelecommunicationsRegulatoryBodyforyour
area.
RefertoAppendixCMMSIRegulatorybodiesand
applicationsubmissions
foralistofcontactsforobtainingMMSInumbersfor
someareas.
Warning:MMSIentry
Y oucanonlyenteraMMSInumberonce,if
youenterthenumberincorrectlyorneed
tochangeyourMMSInumber,theunitwill
requirere-programmingbyanauthorized
dealer.
2.6AutomaticTransmitter
IdentificationSystem(ATIS)
Y ourproductincludesATISfunctionalityforuseonthe
inlandwaterwaysofcontractinggovernmentsofthe
“Regional Arrangement on the Radiocommunication
Service for Inland Waterways” —alsoknownas
“RAINWAT” .
ATISaddsdataattheendofradiotransmissionsthat
identifiesyourstation.ATISoperationcanbeturnedon
oroffasneededviatheradio’smenu.
AnATISIDcanbeobtainedfromthesameagencythat
issuesradiooperatorlicensesinyourarea.
Y ourATISIDshouldbeprogramedintoyourproduct
usingtheinstructionsprovided.
Note:
ContractingRAINWATcountriesinclude:Austria,
Belgium,Bulgaria,Croatia,theCzechRepublic,
France,Germany,Hungary,Luxembourg,Moldova,
Montenegro,theNetherlands,Poland,Romania,
Serbia,theSlovakRepublicandSwitzerland.
Note:
WhenATISisenabled,certainprogramingsteps
havebeenimplementedtoprotecttheintegrityof
theRAINWATagreement,includingtheblockingof
DSCfunctionswhenATISisenabled.
2.7Partssupplied
Thefollowingpartsaresuppliedwithyourproduct.
Pleaseensureyourboxcontentsarecorrectbefore
proceedingwiththeinstallation.
1.Ray90/Ray91VHFDSCRadio(includingfitted
poweranddatacable)
2.Raymichandsetcradle
3.Raymichandset
4.Raymichandsetadaptorcable(12pinfemaleto12
pinmalewithRCAAudio)
5.Passivespeaker
6.Passivespeakermountinggasket
7.Passivespeakermountingscrewsx4
8.Documentation
9.VHFradiomountingscrewsx4
10.Handsetcradlemountingscrewsx4
11.DeviceNettoSeaTalkng®adaptor
16
