Raymarine ST60+ SPEED INSTRUMENT - Control Unit

4.3 in (109 mm)
4.47 in (113.5 mm)
Sun cover edge
Instrument edge
Remove material from shaded area only
Drill hole,
1/4 in (6.5 mm)
diameter in
4 positions
TOP
Control Unit
FLUSH MOUNT
Template
FLUSH MOUNT template for
ST60+ Instruments
