Instruction Manual TR-Mark III 250V Version 1.10 Preliminary Page 11 of 57
4.2.2 Comparison of International Standards
High Winding Side:
Wire Color ANSI Wire Color IEC Wire Color Australian
RED H1 RED U RED A
BLACK H2 BLACK V WHITE B
WHITE H3 BLUE W BLUE C
YELLOW H0 YELLOW N BLACK N
Low Winding Side:
Wire Color ANSI Wire Color IEC Wire Color Australian
RED X1 RED u RED a
BLACK X2 BLACK v WHITE b
WHITE X3 WHITE w BLUE c
YELLOW X0 YELLOW n BLACK n
NOTE
This manual refers to the ANSI standards for all examples. To change
the standard in the test instrument please refer to chapter ‘8.6.1’
WARNING!
BEFORE OPERATING THIS OR ANY OTHER TEST EQUIPMENT
READ ALL SAFETY WARNINGS AND UNDERSTAND THEM FULLY.
DO NOT VARY INPUT VOLTAGE (MAINS) AFTER POWERING ON
TEST SET.
The TR-Mark III 250V auto-senses the input (mains) voltage from 100
to 250 vac 50 / 60 Hz.
The TR-Mark III 250V then “locks–in” the test voltage range. If the
input voltage (mains) is varied after the TR-Mark III 250V was powered
on the actual test voltage may be higher or lower than indicated.
