Raytech TR–Mark III 250V - Rack-Mounted Unit Operation Elements; Rack Front Panel Layout; Rack Rear Panel Layout

Instruction Manual TR-Mark III 250V Version 1.10 Preliminary Page 14 of 57
6 Operation Elements Rack
Please find legend of elements on previous page.
6.1 Rack: Front Panel Overview
6.2 Rack: Rear Panel Overview
1 Mains Switch
2: Ground Terminal
3: Emergency Stop
4: High Voltage Side
5: Low Voltage Side
6: 3 Phase
Extension
(T-REX)
7: External
(Touch
Changer)
8: Interface
(USB and RS232)
9: Safety
Indicator
8: Interface (USB)
10: Display and
Touch Panel
1: Fuse and
Mains Input
