RayTek MARATHON FA - Electrical Specifications

TechnicalData
6 MarathonSeriesFA/FR
WarmupPeriod 15minutes
Weight
OpticalHead 100g(3.5oz)
ElectronicsHousing 710g(9oz)
3.3ElectricalSpecifications
PowerSupply 24VDC±20%,500mA(max100mVpeaktopeakofripple)
PowerConsumption max.12W
OutputIsolation 500VACorDCprovidedbymanufacturersuppliedpower
supplyaccessory
DielectricWithstandVoltage 500V
Outputs
Analog 0‐20mA,4‐20mA,16bitresolution
max
currentloopimpedance:500Ω
DigitalRS485 networkableto32sensors
Baudrate:300,1200,2400,9600,19200,38400(default)
Adjustablebaudrateonlyavailablethrough2‐wayRS485.
Dataformat:8bit,noparity,1stopbit,
Softwareselectable4‐wire,full‐duplexnon‐multidrop,point‐to‐
pointor
2‐wirehalfduplexmultidrop
Relay Contactsmax.48V,300mA,responsetime<2ms,(software
programmable)
Input
ExternalReset TTLinput,triggerforresettingpeakorvalleyhold

Figure1:ExternalResetWiringDiagram
Sensor
Tri
gg
er
GND
