ProgrammingGuide
44 MarathonSeriesFA/FR
9.6CommandExamples
HOST SENSOR HOST SENSOR WHERE USED (1)
Description
Query 
Answer
Set 
Notification P B S N
Burst string format 001?$ 001!$UTSI 001$=UTSI √ √
Show list of commands 001? √
Measured attenuation 001?B 001!B12 √ √
Baud rate 001!D384 001D=384 √
Emissivity 001?E 001!E0.95 001E=0.95 001#E0.95 √ √ √ √
Average time 001?G 001!G001.2 001G=001.2 001#G001.2 √ √ √ √
Top of mA range 001?H 001!H2000 001H=2000 001#H2000 √ √ √
Sensor internal ambient 001?I 001!I028 √ √
Switch panel lock 001?J 001!IJL 001J=L √ √
Relay alarm output control 001!K0 001K=0 √ √
Bottom of mA range 001?L 001!L1200 001L=1200 √ √ √
Mode – FR series 001?M 001!M1 001M=1 001#M1 √ √ √ √
Target temperature, 1-color narrow 001?N 001!N1158 √
Output current 001!O10 001O=10 √ √ √
Peak hold time 001?P 001!P005.6 001P=005.6 001#P005.6 √ √ √ √
Power 001?Q 001!Q0036.102 √ √
Narrow Power 001?R 001!R0002.890 √ √
Slope 001?S 001!S0.850 001S=0.850 001#S0.850 √ √ √ √
Target temperature, 2-color (FR only) 001?T 001!T1225 √ √
Temperature units 001?U 001!UC 001U=C 001#UC √ √ √ √
Poll/Burst mode 001!VP 001V=P √
Target temperature, 1-color wide 001?W 001!W1210 √ √
Burst string contents 001?X$ √
Multidrop address 001?XA 001!XA013 001XA=013 √ √ √
Low temperature limit 001?XB 001!XB √
Deadband 001?XD 001!XD12 001XD=12 √ √
Restore factory defaults 001!XF XF 001#XF √ √
High temperature limit 001?XH 001!XH1400 √
Sensor initialization 001?XI 001!XI0 001XI=0 001#XI √ √ √ √
Laser 001?XL 001!XL1 001XL=1 001#XL1 √ √ √
Sensor model type 001?XM 001!XR √
0-20 mA or 4 - 20 mA analog output 001?XO 001!XO4 001XO=4 √ √
Second setpoint 001?XP 001!XP1234 001XP=1234 √ √
Sensor revision 001?XR 001!XRF1 √
Setpoint / relay function 001?XS 001!XS1234 001XS=1234 √ √
Trigger 001?XT 001!XT0 001#XT0 √ √ √
Identify unit 001?XU 001!XUFR1 √
Sensor serial number 001?XV 001!XVA099901 √
Attenuation to activate relay 001?Y 001!Y95 001Y=95 √ √ √
Attenuation for failsafe 001?Z 001!Z99 001Z=99 √ √ √
Table7:CommandExamples
(1) P=PollMode(Requestforaparameters),B=BurstMode(continuoussendingofparametersintheburststring),S=Set
(Commandforsettingaparameters),N=Notification(Acknowledgmentforsettingaparameter)


The givenexamples are relatedto aunit in anetwork addressedwith address 001. Stand‐alone
unitsarerequestedwithouthavinganaddressinformationinthecommand.
