Options
MarathonSeriesFA/FR 33
7Options
Optionsareitemsthatarefactoryinstalledandmustbespecifiedattimeoforder.Thefollowingare
available:
• Fiberopticcablelengths:1,3,6,10m(3,10,20,33ft),22m(72ft)forselectedmodels
• ISOCalibrationCertificate,basedonNIST/DKDcertifiedprobes(XXXFR1CERT)
•
HighTemperatureFiberCable(…H),ratedto315°C(600°F),notavailableonFA2models
• LaserSighting(…L)onlyonFA1A/FA2AandFR1A/FR1Bmodels
• CoolingPlatformforElectronicsHousing(...W)

TheHighTemperatureFiberCableexcludesVitoncoatingandIP65(NEMA‐4)rating!
7.1CoolingPlatformforElectronicsHousing
Thecoolingplatformfortheelectronicshousingcanbeusedforambienttemp eraturesupto150°C
(302°F). For an efficient cooling a water flow of 2 l (0.53 gallons) per minute is recommended at a
watertemperatureof16°C(61°F).
Mountinghole:Ø5mm(0.188);max.fastenerhead:8mm
(0.31)
 
Figure30:CoolingPlatformforElectronicsHousing
