EPIC-W FORMATS
The table below describes the formats for RED EPIC-W™.
The table below omits rows for the anamorphic formats, since the pixel dimensions for each anamorphic format and
the corresponding non-anamorphic format are the same. For more information, go to "Anamorphic" on page105.
Using a 6:5 aspect ratio at 2x anamorphic gives you a 2.4:1 aspect ratio.
RESOLUTION DIMENSIONS (PIXELS) DIMENSIONS (MM)
 WIDTH HEIGHT WIDTH HEIGHT DIAGONAL
8K FF 8192 4320 29.90 15.77 33.80
8K 2:1 8192 4096 29.90 14.95 33.43
8K 2.4:1 (WS) 8192 3456 29.90 12.61 32.45
8K 16:9 (HD) 7680 4320 28.03 15.77 32.16
8K 14:9 6720 4320 24.53 15.77 29.16
8K 3:2 6480 4320 23.65 15.77 28.43
8K 6:5 5184 4320 18.92 15.77 24.63
8K 4:1 8192 2048 29.90 7.48 30.82
8K 8:1 8192 1024 29.90 3.74 30.13
7.5K FF 7680 4080 28.03 14.89 31.74
7.5K 2:1 7680 3840 28.03 14.02 31.34
7.5K 2.4:1 (WS) 7680 3240 28.03 11.83 30.42
7.5K 16:9 (HD) 7296 4104 26.63 14.98 30.55
7.5K 4:1 7680 1920 28.03 7.01 28.89
7.5K 8:1 7680 960 28.03 3.50 28.25
7K FF 7168 3780 26.16 13.80 29.58
7K 2:1 7168 3584 26.16 13.08 29.25
7K 2.4:1 (WS) 7168 3024 26.16 11.04 28.40
7K 16:9 (HD) 6720 3780 24.53 13.80 28.14
7K 6:5 4536 3780 16.56 13.80 21.55
7K 4:1 7168 1792 26.16 6.54 26.97
7K 8:1 7168 896 26.16 3.27 26.37
6.5K FF 6656 3536 24.29 12.91 27.51
6.5K 2:1 6656 3328 24.29 12.15 27.16
6.5K 2.4:1 (WS) 6656 2808 24.29 10.25 26.37
6.5K 16:9 (HD) 6144 3456 22.43 12.61 25.73
6.5K 4:1 6656 1664 24.29 6.07 25.04
6.5K 8:1 6656 832 24.29 3.04 24.48
