DISPLAYS AND ELECTRONIC VIEWFINDERS
RED offers the following displays and electronic viewfinders (EVFs):
NOTE: RED offers multiple mounting solutions for each camera type.
Item Resolution Tilt
(Approximate)
Swivel
(Approximate)
Part Number
DSMC2 RED Touch 7.0" LCD (Woven CF)
1
1920 x 1136 Total: 180°
Forward: 90°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0018
DSMC2 RED Touch 7.0" LCD (Aluminum)
1
1920 x 1136 Total: 180°
Forward: 90°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0024
DSMC2 RED Touch 4.7" LCD
1
1280 x 720 Total: 240°
Forward: 90°
Backward: 150°
No swivel 730-0019
RED Touch 5.0" LCD
2
800 x 400 Total: 270°
Forward: 180°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0008
RED Touch 7.0" LCD
2, 3
1920 x 1136 Total: 180°
Forward: 90°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0007
RED Touch 9.0" LCD
2
1280 x 768 Total: 270°
Forward: 180°
Backward: 90°
Total: 360°
CW: 180°
CCW: 180°
730-0011
RED PRO LCD 7"
2
1024 x 600 No tilt No swivel 730-0009
RED PRO Touch 7.0" LCD2 1920 × 1136 No tilt No swivel 730-0025
DSMC2 RED EVF (OLED)
2
1920 x 1080 N/A N/A 730-0021
BOMB EVF
®
(LCOS)
2
1280 x 784 N/A N/A 730-0004
BOMB EVF (OLED)
2
1280 x 1024 N/A N/A 730-0010
1. Using this display with an EPIC or SCARLET camera requires a DSMC2 LEMO Adaptor B.
2. Using this display with a DSMC2 camera requires a DSMC2 LEMO Adaptor A.
3. The RED Touch 7.0" LCD requires that your camera is on firmware v5.2.38 or later.
For a full list of LCD and EVF user keys and default actions, go to "Default Key Functions" on page256.
