Red Dragon WEAPON/EPIC-W - DSMC2 BASE EXPANDER

DSMC2 BASE EXPANDER
Figure: DSMC2 Base Expander
# CONNECTOR CONNECTOR
TYPE
FOR MORE INFORMATION, GO TO...
1 Stereo
Microphone
3.5mm stereo "Stereo Microphone" on page233
2 Headphone Jack 3.5mm stereo "Headphone" on page234
3 SYNC 4-pin 00B LEMO "SYNC (Video Sync In) with SYNC Trigger Button Circuit" on
page223
4 CTRL 4-pin 00B LEMO "CTRL (RS232 Control)" on page227
5 HDMI
®
HDMI 1.2, Type A "HDMI Out" on page222
6 HD-SDI BNC "3G-SDI (HD-SDI) Out" on page221
7 DC IN 6-pin 1B LEMO "DC IN (Power Input)" on page235
C OPYRI GHT © 2017 R ED.C O M , I NC 955- 01 38 _V6.3, REV-D | 216
