WEAPON/EPIC-W OPERATION GUIDE
C
INPUT/OUTPUT
CONNECTORS
This appendix provides pinout information for the input/output connectors on the following expanders:
DSMC2™ Base Expander
DSMC2 V-Lock I/O Expander
DSMC2 REDVOLT Expander
DSMC2 Jetpack Expander
DSMC2 Jetpack-SDI Expander
NOTE: When connecting a cable to a connector, align the key and red marker on the cable connector with the
corresponding key and marker on the device connection.
NOTE: Connector diagram images are for reference only. Diagrams are not to scale.
