EPIC-W TECHNICAL SPECIFICATIONS
EPIC-W TECHNICAL SPECIFICATIONS
SPECIFICATION DESCRIPTION
Sensor Type HELIUM™ 35.4 Megapixel CMOS
Effective Pixels 8192 x 4320
Sensor Size 29.90 mm x 15.77 mm (Diagonal: 33.80 mm)
Dynamic Range 16.5+ stops
Signal-to-Noise
Ratio
80 dB
Max Data Rates Up to 275 MB/s using RED MINI-MAG® (480GB, 512GB, 960GB & 1TB)
Up to 225 MB/s using RED MINI-MAG (120GB & 240GB)
Max Frame
Rates
1
30 fps at 8K Full Format (8192 x 4320), 30 fps at 8K 2.4:1 (8192 x 3456)
30 fps at 7K Full Format (7168 x 3780), 40 fps at 7K 2.4:1 (7168 x 3024)
75 fps at 6K Full Format (6144 x 3240), 100 fps at 6K 2.4:1 (6144 x 2592)
96 fps at 5K Full Format (5120 x 2700), 120 fps at 5K 2.4:1 (5120 x 2160)
120 fps at 4K Full Format (4096 x 2160), 150 fps at 4K 2.4:1 (4096 x 1728)
150 fps at 3K Full Format (3072 x 1620), 200 fps at 3K 2.4:1 (3072 x 1296)
240 fps at 2K Full Format (2048 x 1080), 300 fps at 2K 2.4:1 (2048 x 864)
Playback Frame
Rates
(Project Time
Base)
23.98, 24, 25, 29.97, 47.95, 48, 50, 59.94, 60 fps, all resolutions
REDCODE
®
Settings
(Range from 2:1
up to 22:1)
1
6:1 REDCODE for 8K Full Format (8192 x 4320) at 24 fps
7:1 REDCODE for 8K Full Format (8192 x 4320) at 30 fps
2:1 REDCODE for 4K Full Format (4096 x 2160) at 24 fps
4:1 REDCODE for 4K Full Format (4096 x 2160) at 60 fps
REDCODE RAW
Acquisition
Formats
8K Full Format (8192 x 4320), 2:1, 2.4:1, 16:9, 14:9, 3:2, 6:5, 4:1, 8:1, and Ana 2x, 1.3x, 1.25x
7K Full Format (7168 x 3780), 2:1, 2.4:1, 16:9, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
6K Full Format (6144 x 3240), 2:1, 2.4:1, 16:9, 3:2, 4:3, 6:5, 4:1, 8:1, and Ana 2x, 1.3x, 1.25x
5K Full Format (5120 x 2700), 2:1, 2.4:1, 16:9, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
4K Full Format (4096 x 2160), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, 1:1, and Ana 2x, 1.3x
3K Full Format (3072 x 1620), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
2K Full Format (2048 x 1080), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
Apple
®
ProRes 422 HQ, 422 and 422 LT at 4K (4096 × 2160) up to 29.97 fps
4444 XQ and 4444 at 2K (2048 × 1080) up to 120 fps
422 HQ, 422 and 422 LT at 2K (2048 × 1080) up to 120 fps
