RECORD
Perform one of the following actions to begin recording:
Press PWR/REC on the camera.
Press REC on the media bay.
Press START/STOP on the DSMC2 Top Handle or DSMC2 Outrigger Handle.
Double-tap the right 25% on an attached touchscreen display (when enabled).
NOTE: To enable Double-Tap Right 25% to Record, go to Menu > Settings > Display > Monitor Control >
Advanced > Gestures.
RECORD VIA HD-SDI OR HDMI
NOTE: HD-SDI and HDMI ports are only available on select DSMC2 expanders. For more information, go to
"Input/Output Connectors" on page215.
NOTE: The secondary LCD/EVF port (on the side of the camera) and the HDMI port cannot be used at the same time.
For more information, go to "LCD/EVF 2 / HDMI Select" on page84.
This section describes how to record via HD-SDI or HDMI through simultaneous record (recording to an SSD and an
external recorder at the same time) or external record only.
SIMULTANEOUS RECORD
NOTE: HD-SDI and HDMI ports are only available on select DSMC2 expanders. For more information, go to
"Input/Output Connectors" on page215.
You can record simultaneously to an external recorder and a RED SSD. To record simultaneously, follow the
instructions below:
1. Attach a DSMC2 expander that has an HD-SDI or HDMI port.
2. Connect the camera to an external recorder with an HD-SDI or HDMI cable.
3. Ensure an SSD is inserted in the camera and formatted.
4. Set up the HD-SDI or HDMI output:
A.
Go to Menu > Settings > Display > Monitor Control > Monitor Setup.
B.
Select HDMI or HDSDI from the drop-down menu at the top of the menu.
C.
Select Clean from the Mode drop-down menu (otherwise the external recorder records the overlay).
D.
Select the output resolution from the Resolution drop-down menu.
NOTE: The HDMI and HD-SDI maximum resolution is 1080p. For more information, go to "Record/Monitor Out
Ports" on page221.
5. Disable all False Colors (otherwise the external recorder records the False Colors):
A.
Go to Menu > Settings > Display > Tools.
B.
Select Off from the False Color drop-down menu.
6. If monitoring audio via a third-party monitor that supports audio, set up the monitor mix:
A.
Go to Menu > Settings > Audio > Mix > Monitor Mix.
B. Adjust the input channels.
7.
Go to Menu > Settings > Recording > Mode.
8.
Select Local from the Storage drop-down menu.
9. Begin recording.
