AVID DNXHD AND AVID DNXHR INFORMATION
By default, the camera records all videos and stills in the REDCODE RAW file format (records R3D files). You also
have the option to record to Avid DNxHD and Avid DNxHR (records .mxf files). This section provides general
information about recording Avid DNxHD/HR with the camera:
Selecting a Recording Frame Rate that is not supported by Avid DNxHD/HR causes the codec file to be sub-
sampled to half of the selected Recording Frame Rate.
The camera cannot record Avid DNxHD/HR when Pre-Record is enabled.
The camera can record Avid DNxHD/HR only when either of the following recording modes is enabled:
Continuous Record
Motion + Stills
If HDRX
®
is enabled, only the selected monitor track is recorded to the Avid DNxHD/HR file. For more information,
go to "HDRX Menu" on page145
RED recommends performing a Secure Format before recording Avid DNxHD/HR. For more information, see the
DSMC Media Operation Guide, available at www.red.com/downloads.
The .mxf files have the same metadata that is in the REDCODE RAW files. The metadata is per clip, and not per
frame. At this time, there is no tool for extracting that metadata from the .mxf files.
You can select any Resolution in the Format menu. When recording Avid DNxHD/HR, the camera scales that format
to the Resolution (2K or 4K) selected in the Codec menu. The field of view is maintained in Avid DNxHD/HR; the
image is not cropped. For more information on setting the Format, go to "Format" on page97.
Enabling Lookaround effects the aspect ratio of the scaled file, regardless of the recorded area.
If recording 4K Avid DNxHD/HR and the Resolution is less than 4K, the image is scaled to 2K.
For more information about Avid DNxHD/HR, see the Avid website at www.avid.com/en/products/avid-dnxhr-and-
dnxhd.
AVID DNXHD AND AVID DNXHR DESCRIPTION
The table below describes each Avid DNxHD/HR codec.
NAME CODEC ID BITS COLOR
DNxHR HQX 1271 12 bit YCbCr 4:2:2
DNxHR HQ 1272 8 bit YCbCr 4:2:2
DNxHR SQ 1273 8 bit YCbCr 4:2:2
DNxHR LB 1274 8 bit YCbCr 4:2:2
DNxHR 444 1270 12 bit RGB 4:4:4
DNxHD 444 1256 10 bit RGB 4:4:4
DNxHD HQX 1235 10 bit YCbCr 4:2:2
DNxHD HQ 1238 8 bit YCbCr 4:2:2
DNxHD SQ 1237 8 bit YCbCr 4:2:2
DNxHD LB 1253 8 bit YCbCr 4:2:2
