6. Use a Phillips #0 screwdriver to install the screw in the Back Focus Lock position. DO NOT exceed 80 in-oz, or
damage may occur.
WARNING: DO NOT OVERTIGHTEN.
Figure: Lock Back Focus
Figure: Back Focus Successfully Locked
7. Re-install the DSMC2 Sidekick (or side panel). For more information, go to "Install the DSMC2 Sidekick" on
page42.
Figure: Install DSMC2 Sidekick
C OPYRI GHT © 2017 R ED.C O M , I NC 955- 01 38 _V6.3, REV-D | 198
WEAPON/EPIC-W OPERATION GUIDE
