DSMC2 REDVOLT XL MODULE: INSTALL/REMOVE
INSTALL THE DSMC2 REDVOLT XL MODULE
The DSMC2 REDVOLT XL Module mounts to the rear of the following items:
BRAIN
DSMC2 Base Expander
DSMC2 REDVOLT Expander
WARNING: Before installing or removing this item, you MUST turn off the camera.
REQUIRED TOOLS: T20 TORX driver
1. Turn off the camera.
2. Position the module on the rear of the camera or expander, aligning the connector on the front of the module with
the connector on the rear of the camera or expander.
3. Apply pressure and tighten the four (4) captive screws in a cross pattern (“X” pattern) approximately two (2) turns
each using a T20 TORX driver. DO NOT FULLY TIGHTEN.
4. Fully tighten the four (4) screws in a cross pattern (“X” pattern) using a T20 TORX driver.
WARNING: DO NOT OVERTIGHTEN.
REMOVE THE DSMC2 REDVOLT XL MODULE
WARNING: Before installing or removing this item, you MUST turn off the camera.
REQUIRED TOOLS: T20 TORX driver
1. Turn off the camera.
2. Loosen the four (4) captive screws in a cross pattern (“X” pattern) using a T20 TORX driver.
3. Remove the module from the camera or expander.
C OPYRI GHT © 2017 R ED.C O M , I NC 955- 01 38 _V6.3, REV-D | 45
WEAPON/EPIC-W OPERATION GUIDE
