# ITEM SUB-ITEM/DESCRIPTION FOR MORE
INFORMATION, GO
TO...
3 System
Status
Indicators
Tap to access the System Status menu "System Status" on
page135
Temperature: Camera sensor and core temperature, respectively "Sensor Calibration"
on page130
Cal: T/E "CAL: T/E Indicator"
on page64
HDRX: Displays when HDRX mode is on "HDRX Menu" on
page145
False Color Mode: Displays modes "False Color Modes"
on page76
Magnify: Tallies 1:1 if magnify is selected "Magnify" on page78
Timecode "Timecode" on
page164
Genlock "GEN Indicator" on
page64
Sync "SYNC Indicator" on
page64
LAN "LAN Indicator" on
page65
RIG: Indicates 3D rig metadata is present N/A
WIFI: Indicates WiFi connection "WiFi Indicator" on
page65
4 Media
Status
Media location and remaining media capacity, displays when recording R3D
and/or Apple
®
ProRes; tap to access the Media Menu
"Media Menu" on
page138
5 Power
Status
DC voltage in or % of remaining battery capacity; tap to access the Power
menu
"Power Status" on
page65
6 Audio
Meter
Audio input selection and levels; tap to access the Audio menu "Audio Meter (VU
Meter)" on page162
