Description of the device
14
English Reflexomat with Touch controller06.07.2016 - Rev. B
4.5
Scope of delivery
The scope of delivery is described in the shipping document and the content is shown on the packaging.
Immediately after receipt of the goods, please check the shipment for completeness and damage. Please notify us immediately of any
transport damage.
Basic pressure-maintaining equipment:
Control unit with one or two compressor(s) including compressed air line(s).
Primary tank with flexible water connection.
"LIS" pressure load cell for level sensing.
4.6
Optional equipment and accessories
Secondary tanks with connection sets for the primary tank.
For make-up with water
Make-up without pump:
Solenoid “Fillvalve” with ball valve and Reflex Fillset for make-up with drinking water.
Make-up with pump:
Reflex Fillcontrol Auto, with integrated pump and a system separation vessel or Auto Compact
For water make-up and degassing:
Reflex Servitec 30 (25)
Reflex Servitec 35-95
Fillset for make-up with drinking water.
With integrated system separator, water meter, dirt trap and locking mechanisms for the "WC" make-up line.
Fillset Impulse with FQIRA+ contact water meter for make-up with drinking water.
Fillsoft for softening or desalination of the make-up water from the drinking water network.
Fillsoft is installed between Fillset and the device. The device controller evaluates the make-up quantities and signals a
required replacement of the softening cartridges.
Optional expansions for Reflex controllers:
I/O module for standard communication.
Master-Slave-Connect for master controllers for maximum 10 devices.
Bus modules:
Lonworks Digital
Lonworks
Profibus DP
Ethernet
Diaphragm rupture monitor
Note!
Separate operating instructions are supplied with
accessories.
