Technical data
Reflexomat with Touch controller — 06.07.2016 - Rev. B English —
15
5
Technical data
5.1
Control unit
Note!
The following values apply for all control units:
–
Permissible flow temperature:
–
Permissible operating temperature:
–
Permissible ambient temperature:
120 °C
70 °C
0 °C – 45 °C
Type
Power
output
(kW)
Power supply
(V / Hz , A)
Degree of
protection
Number of RS-
485 interfaces
I/O
module
Electrical voltage
control unit
(V, A)
Noise level
(dB)
Weight
(kg)
RS 90/1 T 0.75 230 / 50, 3 IP 54 1 No 230, 2 72 32
RS 90/2 1.5 230 / 50, 6.5 IP 54 1 No 230, 2 72 45
RS 150/1 1.1 400 / 50, 5 IP 54 1 No 230, 2 72 45
RS 300/1 2.2 400 / 50, 10 IP 54 1 No 230, 2 76 48
RS 300/2 4.4 400 / 50, 19 IP 54 1 No 230, 2 76 86
RS 400/1 2.4 400 / 50, 10.5 IP 54 1 No 230, 2 76 62
RS 400/2 4.8 400 / 50, 21 IP 54 1 No 230, 2 76 118
RS 580/1 3 400 / 50, 13 IP 54 1 No 230, 2 76 102
RS 580/2 6 400 / 50, 26 IP 54 1 No 230, 2 76 196
