Reflexomat with Touch controller — 06.07.2016 - Rev. B English —
Damage to the pressure load cell due to unprofessional installation
Incorrect installation may result in damage to the "LIS" level sensor, malfunctioning and incorrect measurements from the pressure load
cell.
• Comply with the instructions regarding the installation of the pressure load cell.
The "LIS" level sensor uses a pressure load cell. This pressure pick-up is to be installed after the primary tank has been placed at its final
position, see chapter 6.3.2 "Tank installation" on page 20 . Comply with the following instructions:
• Remove the transport securing device (squared timber) at the vessel base of the primary tank.
• Replace this transport securing device with the pressure load cell.
– In the case of a tank volume of 1000 l (Ø 1000 mm) or more, use the supplied screws to attach the pressure load cell at the
vessel base of the primary tank.
• Avoid shock-type loading of the pressure load cell by, for example, subsequent alignment of the vessel.
• Use flexible hoses to connect the primary tank and the first secondary tank.
– Use only the supplied connection sets, see chapter 6.3.2 "Tank installation" on page 20 .
• Perform a null balancing of the filling level when the primary tank is aligned and fully emptied, see chapter 9.3 "Configuring settings
in the controller" on page 46 .
Standard values for level measurements:
200 l 0 – 4 bar
300 – 500 l 0 – 10 bar
600 – 1000 l 0 – 25 bar
1500 – 2000 l 0 – 60 bar
3000 – 5000 l 0 – 100 bar
