1. General Information
1.1 Specications
X500 3D Printer
The X500 is the answer to the current demand on the market and oers in addition to the large
construction volume of 500 x 400 x 475 (XxYxZ) millimeters further innovations which are the
focus of the requirements of industrial use. With its steel frame and a total weight of approx.
170 kg, the machine oers an extremely high stability. A new extruder technology makes it
possible to process future material developments precisely. The cooling circuit allows a stable
process even at maximum building chamber temperature.
specication data
working space ( X - Y - Z) 500 x 400 x 475 mm / 19.7 x 15.7 x 18.7 in
printing speed 10 - 150 mm/s
travel speed 10 - 300 mm/s
layer thickness (minimal) 0,1 mm
lament diameter (standard) 1,75 Ø mm
nozzle diameter (standard) 0,4 Ø mm (opt.: 0,25 / 0,30 / 0,5 / 0,6 / 0,8)
material
Depending on the application, as well as on size and geometry,
a wide range of materials is available. For more information,
contact your reseller.
extruder type DD4 Dual Extruder
extruder temperature (maximum) 400° / 752 °F
building plate heatable
le transfer
Stand-alone Printing mit Touch Display, USB-Stick, Ethernet
and WLAN optionally
software Simplify3D Software
power consumption 2500 W
operating voltage* 110 / 230 V
ambient temperature 15-26°C / 59 – 78.8°F
external dimensions approx. (W x D x H) 1050 x 820 x 950 mm / 41.3 x 32.3 x 37.4
weight 170 kg / 375 lbs
Heat Bed (max) 120° / 248 °F
Heated Building Chamber 80° / 176 °F
Options Maintenance Contract
