7.5 Manual Mode
In manual mode, the following parameters can be edited directly:
Speed: Via the control dial, speeds of 6,000 to 23,000 rpm can be set.
Start delay: The control dial can be used to set a delayed start of the device. After pressing the
button, the device is started after a delay according to the preset minutes:seconds (mm:ss)
value. The display counts down to zero in steps of one second.
DR 100 conveying speed: With the DR 100 feed unit connected, the control dial can be used
to set the conveying speed of the optional accessory (0 to 100 % of the max. conveying speed).
Automatic stop: At the control dial an automatic stop of the device and the DR 100 feed unit
can be set when the DR 100 feed unit is connected. The motor load is registered by the device.
If no more motor load changes are detected by the device, the system is stopped after the set
coasting time.
