Controlling the device using the touchscreen display
58
7.6.1 Select a Program
Fig. 36: Functions of the programme mode with DR 100 connected
Element
Description
Function
T2.3
Manual mode
Returns to manual mode.
T2.4
Program overview
Opens the program overview.
T4.1
Open
Opens the lock of the device hood.
T4.3
Scroll bar
Indicator for the position of the respective menu interface or
program.
T4.5
Edit programs
Opens the "Edit program" function.
Press the button to switch to program mode. The display switches to the current program.
The program number is displayed next to the symbol.
 Swipe from right to left or from left to right on the touch display in the "Parameter settings and
display" control element area to navigate through the programs. The position of the programme
is shown in the scroll bar.
Alternatively, the programme overview can be accessed by pressing . Each program is
presented in a section.
 Swipe the display in the control element area "Parameter settings and display" to switch
between program groups 1 to 4 and 5 to 8.
 To activate a program, press the upper third of the desired program section.
T2.3
T4.1
T4.3
T2.4
T4.5
