Controlling the device using the touchscreen display
59
Fig. 37: Programs in the program overview with DR 100 connected
Element
Description
Function
T2.3
Manual mode
Manual mode or return to manual mode
T3.5
Program sections
Displays the current parameters of the programs.
T4.3
Scroll bar
Indicator for the position of the program overview.
 Press to start the selected program and the grinding process.
 To exit programme mode and return to manual mode, press .
