REXROTH VFC 3610 - Page 11

Fig. 1-7: VFC 5610 160K...220K dimensions figure
Frame
Model
①
Dimensions [mm]
Screw
size
②
Net
weight
[kg]
W H
D
④
w h
d
④
Ø
B 0K40 95 166 167 66 156 159 4.5 M4 1.5
B 0K75 95 166 167 66 156 159 4.5 M4 1.5
C 1K50 95 206 170 66 196 162 4.5 M4 1.8
D 2K20 120 231 175 80 221 167 4.5 M4 2.6
Tab. 1-2: VFC x610 1P 200 VAC dimensions
Frame
Model
①
Dimensions [mm]
Screw
size
②
Net
weight
[kg]
W H
D
④
w h
d
④
Ø
B 0K40 95 166 167 66 156 159 4.5 M4 1.5
B 0K75 95 166 167 66 156 159 4.5 M4 1.5
C 1K50 95 206 170 66 196 162 4.5 M4 1.8
C 2K20 95 206 170 66 196 162 4.5 M4 1.8
D 3K00 120 231 175 80 221 167 4.5 M4 2.6
D 4K00 120 231 175 80 221 167 4.5 M4 2.6
E 5K50 130 243 233 106 228 225 6.5 M6 3.6
Rexroth Frequency Converter VFC
3610 / VFC 5610
5/91
Mechanical Installation
R912005518_Edition 16 Bosch Rexroth AG
