Model W w1 w2 H h1 h2 h3 h4
15K0 180 150 125 285 270 - 136 253
22K0 195 180 140 315 300 150 76 282
45K0 315 290 260 570 550 250 150 520
55K0 315 290 260 570 550 250 150 520
75K0 375 350 300 760 730 250 141.5 690
Model h5 D d1 Ø R
Screw
size
Net weight
(Kg)
15K0 - 170 57 6.5 30 M6 6.5
22K0 - 180 67 6.5 40 M6 8.0
45K0 534.5 200 76 11 40 M10 27.0
55K0 534.5 200 106 11 40 M10 32.0
75K0 705 207 129 11 40 M10 44.0
Wall-Through models are only support HD (Heavy Duty) mode.
Rexroth Frequency Converter VFC
3610 / VFC 5610
9/91
Mechanical Installation
R912005518_Edition 16 Bosch Rexroth AG
