VFC x610
Model
Fuse (Class J) Power cables PE Cable Torque / Screw
[A] [AWG] [AWG] [N·m / lbf·in] (Mx)
110K 300.0
400 kcmil
3 / 0
15.0 / 132.7 (M10)
①
3 / 0 * 2
8.0 / 70.8 (M8)
②
132K 350.0
500 kcmil
250 kcmil
15.0 / 132.7 (M10)
①
250 kcmil * 2
8.0 / 70.8 (M8)
②
160K 450.0 350 kcmil * 2 350 kcmil
15.0 / 132.7 (M10)
②
185K 450.0 350 kcmil * 2 350 kcmil
15.0 / 132.7 (M10)
②
200K 500.0 300 kcmil * 2 300 kcmil
15.0 / 132.7 (M10)
②
220K 500.0 350 kcmil * 2 350 kcmil
15.0 / 132.7 (M10)
②
Tab. 2-4: 3P 380 VAC fuse and cable dimensions for USA / Canada
①
and
②
: According to the actual situation, single cable or double ca-
ble can be selected as the power cable of model 110K and above.
①
is the torque and screw of single cable and
②
is the torque and
screw of double cable.
18/91
Electric Installation
Rexroth Frequency Converter VFC
3610 / VFC 5610
Bosch Rexroth AG R912005518_Edition 16
