Code Name Setting range Default Min. Attri.
C3.41 Torque reference channel
0: AI1 analog input
1: AI2 analog input
2: Panel potentiometer
3: EAI1 analog input
4: Pulse input via DI5
5: Parameter setting
C3.46
6: Communication (Mod-
bus 0x7F02/Fieldbus ex-
tension card H0.12)
7: EAI2 analog input
0 – Stop
C3.42
Torque reference minimum value
①
0.0 %…[C3.43] 0.0 0.1 Run
C3.43
Torque reference maximum value
①
[C3.42]…200.0 % 150.0 0.1 Run
C3.44
Torque positive limit
①
0.0…200.0 % 150.0 0.1 Run
C3.45
Torque negative limit
①
0.0…200.0 % 150.0 0.1 Run
C3.46 Digital torque reference setting 0.0...200.0 150.0 0.1 Run
C3.47
Torque limitation reference selec-
tion at speed control mode
0: Parameter C3.44 and
C3.45
1: AI1 (0.0...200.0 %)
2: AI2 (0.0...200.0 %)
3: EAI1 analog input
4: Communication
(Torque FWD limitation
register: Modbus 0x7F03/
Fieldbus extension card
H0.14)
(Torque REV limitation reg-
ister: Modbus 0x7F04/
Fieldbus extension card
H0.15)
5: EAI2 analog input
0 - Stop
