Code Name Setting range Default Min. Attri.
E3.54 Multi-speed frequency 15 0.00...[E0.09] Hz 0.00 0.01 Run
E3.59 Stage 0 frequency source
0: Digital setting frequency
1: AI1 analog input
2: AI2 analog input
3: EAI1 analog input
4: X5 pulse input
5: Communication
6: Panel potentiometer
7: Digital input up/down command
8: EAI2 analog input
0 – Stop
E3.60 Stage 0 action
011, 012, 013, 014, 015, 016 ,017,
018, 021, 022, 023, 024, 025, 026,
027, 028, 031, 032, 033, 034, 035,
036, 037, 038, 041, 042, 043, 044,
045, 046, 047, 048, 051, 052, 053,
054, 055, 056, 057, 058, 061, 062,
063, 064, 065, 066, 067, 068, 071,
072, 073, 074, 075, 076, 077, 078,
081, 082, 083, 084, 085, 086, 087,
088, 111, 112, 113, 114, 115, 116,
117, 118, 121, 122, 123, 124, 125,
126, 127, 128, 131, 132, 133, 134,
135, 136, 137, 138, 141, 142, 143,
144, 145, 146, 147, 148, 151, 152,
153, 154, 155, 156, 157, 158, 161,
162, 163, 164, 165, 166, 167, 168,
171, 172, 173, 174, 175, 176, 177,
178, 181, 182, 183, 184, 185, 186,
187, 188
011 – Stop
E3.62 Stage 1 action 011 – Stop
E3.64 Stage 2 action 011 – Stop
E3.66 Stage 3 action 011 – Stop
E3.68 Stage 4 action 011 – Stop
E3.70 Stage 5 action 011 – Stop
E3.72 Stage 6 action 011 – Stop
E3.74 Stage 7 action 011 – Stop
E3.76 Stage 8 action 011 – Stop
E3.78 Stage 9 action 011 – Stop
E3.80 Stage 10 action 011 – Stop
E3.82 Stage 11 action 011 – Stop
E3.84 Stage 12 action 011 – Stop
E3.86 Stage 13 action 011 – Stop
E3.88 Stage 14 action 011 – Stop
E3.90 Stage 15 action 011 – Stop
E3.61 Stage 0 running time 0.0...6,000.0 s 20.0 0.1 Stop
E3.63 Stage 1 running time 0.0...6,000.0 s 20.0 0.1 Stop
E3.65 Stage 2 running time 0.0...6,000.0 s 20.0 0.1 Stop
E3.67 Stage 3 running time 0.0...6,000.0 s 20.0 0.1 Stop
E3.69 Stage 4 running time 0.0...6,000.0 s 20.0 0.1 Stop
E3.71 Stage 5 running time 0.0...6,000.0 s 20.0 0.1 Stop
E3.73 Stage 6 running time 0.0...6,000.0 s 20.0 0.1 Stop
E3.75 Stage 7 running time 0.0...6,000.0 s 20.0 0.1 Stop
E3.77 Stage 8 running time 0.0...6,000.0 s 20.0 0.1 Stop
E3.79 Stage 9 running time 0.0...6,000.0 s 20.0 0.1 Stop
