ASMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 38
Model:
The model designator of this unit.
Unit ID:
This field reports the unique ID number that has been assigned by the Remote Manager application (If being used). If the unit
is not managed through the Manager application, this will normally be 0.
Firmware version:
The version of the firmware.
GUI version:
The version of the Graphical User Interface.
Hardware Revision:
The hardware revision status of the unit. Future hardware revision levels may add additional capabilities.
Unit Serial Number:
The serial number of this unit.
SD-Card IDs and Serial Number:
The internal SD storage card’s brand/type identification and serial numbers.
Date, Time:
The date and time as maintained by the on-board real time clock. Refreshing the page will update this information.
Alarm Summary:
Fault Summary:
This is the overall system alarm summary status. It will be active if any of the alarms below it are active.
Isolation Tests:
This alarm will activate if any of the System Isolation Tests values are outside the min. or max. threshold levels.
Rx Power:
This alarm will activate if any of the Rx channels are detecting a received signal level outside the programmed min/max threshold
levels.
Tx Power:
This alarm will activate if any of the Tx channels are detecting a forward power level outside the programmed min/max threshold
levels.
Tx VSWR:
This alarm will activate if any of the Tx channels is detecting a VSWR level above its configured max VSWR level.
