ASMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 14
4. Coupler - Electrical and Mechanical Specifications
Coupler Model Number
SPxxxx-2440-DFF1RU / SPxxxx-4440-DFF1RU
Frequency range
SP1318-2440-DFF1RU 130-180MHz
SP3855-4440-DFF1RU 380-550MHz
SP7496-4440-DFF1RU 746-960MHz
Insertion Loss
< 0.2dB
Input and Output Port Return Loss
> 20dB
Coupling Loss
40dB (+/- 0.7)
Maximum input power
750W
Maximum PIP
16kW (+72dBm)
PIM 3rd OIP (2 x 43dBm carriers)
Better than -150dBc
Connectors – “To ANT” & “From COMBINER” ports
2 x 7/16 DIN (F)
Connectors – “FWD” and “RFL” coupling ports
2 x N (F)
Mounting
1RU 19" rack mounting
Dimensions
W 19 x H 1.75 x D 3" / W 483 x H 45 x D 77mm (inc connectors)
Weight
SP1318-2440-DFF1RU < 4.4lbs / 2kgs
SP3855-4440-DFF1RU < 2.2lbs / 1kg
SP7496-4440-DFF1RU < 2.2lbs / 1kg
Operational temperature range
-22°F to 140°F / -30°C to +60°C
5. CAM/SAM/RSM - Electrical and Mechanical Specifications
CAM Model Number
CAM0000
Alarm Outputs
10
Alarm Contact Type
Dry Relay N.O. / Common / N.C.
Alarm Relay Contact Ratings
50VDC @ 1A
Alarm Inputs
10 (configurable - one per alarm output)
4 (configurable – general purpose)
Alarm Input Logic
“0” = <2.5V DC “1” = >2.5V DC
Visual alarm notification
Front and Rear panel mounted LEDs
Power Supply options
9-36VDC or 36-60VDC
Power Consumption
10W (max)
Connectors
External Alarm Inputs
Channel Alarms Outputs
Channel Alarms Inputs
Power Supply
Comms Interface to/from ASM
(Note: All connectors on rear)
1 x Polarized 8-pin Phoenix connector
10 x Polarized 3-pin Phoenix connectors
10 x Polarized 2-pin Phoenix connectors
1 x Polarized 2-pin Phoenix connector
1 x DB15 (M)
Mounting
1RU 19" rack mounting
Dimensions
W 19 x H 1.75 x D 3" / W 483 x H 45 x D 77mm
Weight
< 2.2lbs / 1kg
Operational temperature range
-22°F to 140°F / -30°C to +60°C
Table 2
Table 3
