ASMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 15
SAM Model Number
SAM0000 / SAM0000-48
Alarm Outputs
10
Alarm Contact Type
Dry Relay N.O. / Common / N.C.
Alarm Relay Contact Ratings
50VDC @ 1A
Alarm Inputs
10 (configurable) digital (general purpose/one per alarm output)
4 (configurable) temperature/analogue/digital (general purpose)
Alarm Input Logic
temperature RFI temperature sensor
analogue -60V DC to +60V DC
analogue -60V DC to +5V DC
digital “0” = <2.5V DC “1” = >2.5V DC
Temperature Sensor (optional)
SAM0000-TS (ordered separately)
Connector Kit (optional)
SAM0000-CK (ordered separately)
Visual alarm notification
Front and Rear panel mounted LEDs
Power Supply options
9-36VDC (SAM0000)
or
36-60VDC (SAM0000-48)
Power Consumption
10W (max)
Connectors
External Alarm Inputs
Channel Alarms Outputs
Channel Alarms Inputs
Power Supply
Comms Interface to/from ASM
(Note: All connectors on rear)
1 x Polarized 8-pin Phoenix connector
10 x Polarized 3-pin Phoenix connectors
10 x Polarized 2-pin Phoenix connectors
1 x Polarized 2-pin Phoenix connector
1 x DB15 (M)
Mounting
1RU 19" rack mounting
Dimensions
W 19 x H 1.75 x D 3" / W 483 x H 45 x D 77mm
Weight
< 2.2lbs / 1kg
Operational temperature range
-22°F to 140°F / -30°C to +60°C
RSM Model Number
RSM0000 / RSM0000-48
Frequency Range
132-960MHz
Maximum RF Input Level (no damage)
0dBm
Isolation between RF Inputs
>55dB
Peak Detector Response Time
≥ 3mS
Peak Detector Alarm Threshold (GUI selectable per port)
-35 to -55dBm
Peak Detector Warning Threshold (GUI selectable per port)
-40 to -65dBm
Visual alarm notification
Rear panel mounted LEDs
Power Supply options
9-36VDC (RSM0000)
or
36-60VDC (RSM0000-48)
Power Consumption
10W (max)
Connectors
Connection to ASM
RF In and RF Out
Power Supply
Comms Interface to/from ASM
N (Male)
BNC (Female)
1 x Polarized 2-pin Phoenix connector
1 x DB15 (M)
Mounting
On rear of ASM (mounting bracket supplied)
Dimensions
Mounts on rear of ASM
Weight
< 2.64lbs / 1.2kg
Operational temperature range
-22°F to 140°F / -30°C to +60°C
Table 4
Table 5
