6. Ordering Information
Ordering Information
Model Number
Description
ASM1317
Antenna System Monitor 132-174MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC
ASM1317-48
Antenna System Monitor 132-174MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC
ASM1317-AC
Antenna System Monitor 132-174MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC to 90-264V AC (external)
ASM1317-48AC
Antenna System Monitor 132-174MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC to 90-264V AC (external)
ASM3852
Antenna System Monitor 380-520MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC
ASM3852-48
Antenna System Monitor 380-520MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC
ASM3852-AC
Antenna System Monitor 380-520MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC to 90-264V AC (external)
ASM3852-48AC
Antenna System Monitor 380-520MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC to 90-264V AC (external)
ASM7487
Antenna System Monitor 746-870MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC
ASM7487-48
Antenna System Monitor 746-870MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC
ASM7487-AC
Antenna System Monitor 746-870MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC to 90-264V AC (external)
ASM7487-48AC
Antenna System Monitor 746-870MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC to 90-264V AC (external)
ASM8796
Antenna System Monitor 870-960MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC
ASM8796-48
Antenna System Monitor 870-960MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC
ASM8796-AC
Antenna System Monitor 870-960MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC to 90-264V AC (external)
ASM8796-48AC
Antenna System Monitor 870-960MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC to 90-264V AC (external)
Additional Couplers
Description
SP1318-2440-DFF1RU
Directional Coupler 130-180MHz
40dB 4-Port 19in Rack Mount 1RU
Input /Output Ports DIN (F) Coupling Ports N (F)
SP3855-4440-DFF1RU
Dual Directional Coupler 380-550MHz
40dB 4-Port 19in Rack Mount 1RU
Input /Output Ports DIN (F) Coupling Ports N (F)
SP7496-4440-DFF1RU
Dual Directional Coupler 746-960MHz
40dB 4-Port 19in Rack Mount 1RU
Input /Output Ports DIN (F) Coupling Ports N (F)
