2. Table Size:
RichAuto system make the table size as the soft limit values, in order to
prevent machine move over travel，machine size must be less than or equal to the
value of the actual motion displacement machine.
Setting：Enter “Table Size”，press “ ”/“ ” to move cursor to where users
want to modify.Press “ ”，input the new number，press “ ” to save，cursor
auto move to next line，the same operation to change,press “ ” to save all value.
3. Spindle Setup：
Spindle delay：Unit：ms;including start delay and stop delay.
Spindle state：Used to set system using multi-speed or only on/off 2 status, the
corresponding system parameters. System default “3-line 8-state”, if users need
“1-line 2-state(On/Off)”, users can change the number of lines is 1; See detailed
settings at J7 spindle output wiring.
4. Home Setup：
Home speed：Every axis movement speed when back home,system default
speed X.Y: 3000 MM/Minute, Z: 1800 MM/Minute.
Home order：Every axis movement order when back home
Including：
Z,X and Y Z,X,Y Z,Y,X
Z only X and Y,Z X,Y,Z
Y,X,Z XY home X,Y home
Y,X home None home X home only XZ and Y
Home direction：Every axis movement direction when back home,this dirction
depends on the position where home switch is on the machine.If home switch
installed in the positive direction,so home direction should be “positive” ,and vice
